With different design,you can choose volume flow meter or lpg dispenser for propane filling truck. With above gas cylinder refilling truck ,you can start lpg delivery business easily.
Optional propane truck brand:Sinotruk Howo,Dongfeng,ISUZU,FAW,foton and other brands.
●5000liters,5000L,5 cbm
●10,000liters,10000L,10cbm,
●15000 Liters,15000L,15cbm,
●20cbm,20,000liters,20,000L
●35cbm 35,000liters,35,000L
Function: mobile Propane or Butan Gas Delivery/ Refilling/bottling/filling
●2″ Flowmeter or single nozzle filling dispenser machine,
●2″ Corken or Chinese brand vane Pump,
●15/30/40 meters Filling Hose Reel,
●filling nozzle,
●radiator,
●hydraulic oil box
Specifications
Chassis 机壳 Chassis Brand 底盘品牌 Sinotruck HOWO Drive Type 驱动类型 6×4 left/right hand drive Wheelbase(mm) 轴距 4300+1350 mm 4600+1350mm Tire Specifications 轮胎规格 295/80R22.5 The Number of Tires 轮胎数量 10pcs with one spare tire Dimensions(mm) 尺寸 9800×2500×3600 Air Conditioner空调 A/C Brake System 制动系统 Air break Steering Gear 转向装置 Power steering, hydraulic steering with power assistance Gear box 齿轮箱 10 Forwards & 2 Reverse , manual operated Max. driving speed(km/h) 最大速度 95 Engine 引擎 Model型号 Weichai Horsepower(HP) 马力 336hp Emission standard 排放标准 Euro 2/ 3/ 4/ 5 Cylinder No. 气缸数 Diesel,Vertical in-line, water-cooled, six stroke, Fuel type 燃料类型 Diesel Cabin 舱 3 Passengers,single row,1 sleeper
| | |
| Volume: | 20cbm |
| Tank material: | Q345R |
| Tank diameter: | 2000mm |
| Tank thickness: | 10mm |
| End plate | 12mm |
| Tank length: | 6090mm |
| Gas phase | DN50 |
| Liquid Phase | DN80 |
| Filling gas | Propane(LPG) |
| Design Pressure: | 1.61Mpa |
| | |
| Level Gauge | Manual rotation type,at the rear of tank |
| Safety Valve | 1,DN80 |
| Tool and Valve Box | 1 |
| Thermometer | 1 |
| Pressure Gauge | 1 |
| Emergency Valve | 1 |
| Fender | Steel |
| Fire Extinguisher | 2 |
| Exhaust shaft | At the front of truck for safety |
Other LPG tanker products we produce:
We produce the LPG tank , LPG tank trailer, LPG trucks, LPG Skid station, which could be used for loading propane gas, methyl ether gas, isobutane gas, and so on, also include the liquid Ammonia.
Currently we produce the LPG tank, LPG gas storage tank from 3000 liter to 200000 liter.
LPG tank trailer, LPG mobile trailer, from 30000 liter to 60000 liter.
LPG truck, LPG mobile dispener truck, from 3000 liter to 35000 liter.
