Fire Fighting Truck ,which is also called water fire engine,Water Foam Fire Truck,fire fighting equipment, fire appliance truck, foam fire tanker, water foam pumper, light rescue apparatus, fire fighting vehicle, foam discharging truck, foam tanker Fire Truck
is a special vehicle designed primarily for fire fighting operations and to extinguish fire efficiently to prevent fire spread, reducing the loss caused by fire maximumly.
Fire Fighting Truck can be divided into several types:
1--According to vehicle size, there are mini fire fighting truck,light fire fighting truck,medium fire fighting truck, heavy-duty fire fighting truck.
2--According to chassis drive type, there are 4X2 or 6-wheel fire fighting truck, 6X4 or 10-wheel fire fighting truck, 8X4 12-wheel fire fighting truck and off-road type 4X4, 6X6 fire fighting truck for military use.
3--According to chassis brand, there are ISUZU fire fighting truck, Dongfeng fire fighting truck, Foton fire fighting truck, FAW fight fighting truck, Shacman fire fighting truck, sinotruk fire fighting truck, Mercedes fire fighting truck, MAN fire fighting truck,Scania fire fighting truck and so on.
4--According to fire extinguishant,there are water tank fire fighting truck, dry powder fire fighting truck, water/foam fire fighting truck
5-There are also fire rescue truck with special purpose as follows,
--Foam supply fire truck;
--Compressed air supply fire fighting truck;
--Earthquake rescue fire truck;
Fire Tender Rescue Equipment is a main emergency rescue vehicle composed of a chassis and its engine, power generation lighting system, winch traction system and various rescue equipment and protective equipment. It is mainly suitable for highway traffic accidents, building collapses, and dangerous chemicals. Handling of sudden public safety accidents in various places such as product accidents, personnel in distress and social assistance.
FEATURES
● 5 Ton XCMG Crane
● 4kw Light Tower
● 10kw Honda Generator
● 7.5T Electric Winch
● SHACMAN F2000 Fire Truck Chassis
● Weichai 180hp diesel engine
● 4 Firefighter crew seating Cab
● Rear, side compartment with roll up doors
● Top brand LED lighting system
● Full welded steel body, inside wrapped by aluminum
● PTO water pumps or slip-in pump
● Hydraulic rescue tool systems
TECHNICAL SPECIFICATION
| Lifting lamp | BOCAN/ BSD-Z7041000/ 4x1000w/ 7.6m (From top to ground)/ Horizontal 360° Vertical 330°/ Pneumatic/ pneumatic lifting system/ With control cabinet 380/ 220V |
| Hydraulic crane | XCMG/ SQ5ZK2/ Max.Lifting.capacity 5000kg/ Max. Lifting Torque 10.5 T.M/ Max Length of hydraulic arm 8m/ Max Working Height 9m/ Rotation Angle 370°/ Rear-mounted |
| Traction Winch | USA CHAMPION/ N16800XF-24V/ Max traction force 16800lbs (7560kgs)/ Power-driven/ Diameter of wire rope 13mm/ Length of wire rope 48m |
| Generator | HONDA/ SHT11500/ Rated Voltage 220V/ 380V/ Rated Power 10kw/ Movable coil, earthing system equipped/ Starting Mode Electric start and manual |
| Electrical Equipment | Independent circuit; Headlamps are installed in the tools compartment and storage compartment. operating dashboard is equipped with lighting switch, indicator light etc. It is convenient for observation; A set of red and blue flashing lights are installed on both sides of the vehicle body; Long red light 1 piece, which is installed on the top of the cabin; Electronic alarm 1 piece, which is installed in the cabin; The control box is installed below in front of the driver. |
| Chassis | SHACMAN |
| Engine | WP6.180E22/ Weichai/ 180HP/ Euro2 |
| Transmission | 8JS/ FAST/ 8gears+1reverse |
| Cabin | Double-line cabin, with A/C,Center Lock |
| Overall Size | 8,490 x 2,500 x 3,615mm (L×W×H) (app.) |
| Gross Vehicle Weight | 15,300kg (app.) |
| Vehicle Weight | 14,850kg (app.) |
| Wheelbase | 4500 (mm) |
| Max Speed | 90km/h |
| Battery | 24 V |
| Brakes | Air brake |
| Tires | 10.00R20/6+1 Spare Tire |
| Steering | Power assist steering |
| Axles | Front/rear Axle: 4500kg/ 10000kg |
ACCESSORIES
| Item | Item | Parameters | Unit | Quantity |
| 1 | sucking hose | DN150 (4ｍ) | piece | 2 |
| 2 | water filter | FLF150 | piece | 1 |
| 3 | water collector | FJ150 | piece | 2 |
| 4 | 13 type water hose | 13-65－20m | Disc | 3 |
| 5 | 13 type water hose | 13-80－20m | Disc | 3 |
| 6 | 20 type water hose | 20-65－20m | Disc | 3 |
| 7 | 20 type water hose | 20-80－20m | Disc | 3 |
| 8 | triple head distributor | Φ80 inlet Φ65 outlet | piece | 3 |
| 9 | Adapter | Φ80ｍｍ×Φ80ｍｍ | piece | 2 |
| 10 | Foam gun | PQ8 | piece | 1 |
| 11 | Foam gun | PQ16 | piece | 1 |
| 12 | Straight stream water gun | Φ16 mm | piece | 1 |
| 13 | Straight stream water spray gun | | piece | 1 |
| 14 | Foam sucking hose | DN50 | piece | 1 |
| 15 | Foam pipe wrench | FS150 | piece | 2 |
| 16 | hose protector | rubber | pair | 2 |
| 17 | hose hook | FG600 | piece | 8 |
| 18 | hose gaiter | | piece | 8 |
| 19 | fire hydrant wrench | FB450 | piece | 1 |
| 20 | underground fire hydrant wrench | FBA800 | piece | 1 |
| 21 | Sucking pipe wrench | FS150 | piece | 2 |
| 22 | Sole timber | 500X400X50 (mm) | piece | 4 |
| 23 | Rubber hammer | | piece | 1 |
| 24 | Fire axe | | piece | 1 |
| 25 | Chargeable portable lamp | | piece | 2 |
| 26 | Pipe type foam proportioner | | piece | 1 |
| 27 | fire extinguisher | 2kgABC | piece | 1 |
| 28 | Original chassis tools | | piece | 1 |
| 29 | Spare tyre | | piece | 1 |
