1. Purpose: For long distance transportation of concrete to construction site from concrete mixer station.
2. Main parts: Hydraulic pump, hydraulic motor, reducer and radiator etc.
3. Internation brand of main parts: Italy brand PMP, US brand SAUER and Germany brand are optional.
4. More options on c hassis and enigne, such as Foton, Dongfeng, Howo, isuzu, JMC, Shacman, etc
5. Warranty: 1 Year of Engine, Gear box and Driving Axle for Chassis; 1 Year of main parts such as hydraulic pump, hydraulic motor and reducer.
6. Tank material: High strength Q345
7. Engine: Powerful diesel engine
8. PTO: Full - power PTO system
9. Painting and LOGO: We can do the customized design of the painting and LOGO for each customer.
10. Certificate: ISO CCC; We also can supply some certificate as clients' request like BV SGS COC SONCAP FERI
11. Optional for chassis: 4x2, 4x4,6x4, 6x6, 8x4, 8x8 models.
12. 3m3, 5m3, 6m3, 8m3, 9m3, 10m3, 12 m3, 14m3, 16m3, 18m3 etc, many capacity are available to choose.
transit mixer truck with heavy duty, robust and durable structure for toughest job on steep slope in tropical and humid environment at high ambient temperatures. Mixer drum driven separately by an engine. Powerful, fuel efficient with low exhaust emissions. Having improved water / fuel purifying system for increased water / fuel purification and oil bath pre-cleaner for better engine life in dusty environment. Offering best safety features. Easy service and maintenance access design.
The mixer truck takes the power from the power take-off through the rear end of the engine flywheel, and transmits the power to the variable plunger hydraulic pump through the universal joint shaft. The high-pressure oil of the hydraulic pump drives the quantitative plunger motor, and the hydraulic motor transmits the power to the reducer. Drive the mixing drum to rotate forward or reverse to realize feed agitation, stirring or discharging. The output flange of the reducer can be deflected in the range of ±6°, which can compensate for the displacement of the axis of the mixing drum, and ensure that the driving of the mixing drum is not affected by the distortion of the vehicle during the driving process. Chassis 机壳 Chassis Brand 底盘品牌 SHACMAN H3000 Drive Type 驱动类型 8×4 left/right hand drive Wheelbase(mm) 轴距 1800+4100+1350 Tire Specifications 轮胎规格 315/80R22.5 The Number of Tires 轮胎数量 12pcs with one spare tire Dimensions(mm) 尺寸 10200×2500×3650 Air Conditioner A/C Brake System 制动系统 Air break Steering Gear 转向装置 Power steering, hydraulic steering with power assistance Gear box 齿轮箱 10 Forwards & 2Reverse , manual operated Max. driving speed(km/h) 最大速度 95 Engine 引擎 Model型号 Weichai Horsepower(HP) 马力 380HP Emission standard 排放标准 Euro 2/3/4/5 Optional Cylinder No. 气缸数 In-line, 6-cylinder, water cooling, 4-stroke,supercharging intermediate cooler, high pressure common rail Fuel type 燃料类型 Diesel Cabin 舱 1 Sleeper , 3 Passengers,single row
FAQ
1.what can you buy from us?
Answer: Fire Truck ,LPG Tank Truck,Fuel Tank Truck, Tank Truck ,Cleaning Truck,Garbage Truck, Tow Truck ,Bucket Truck,Construction Truck, Ambulance , Van Truck ,Truck Mounted Crane,Utility Truck,Tank Semi Trailer, Semi Trailer
2. What is the payment term?
Answer: FOB,CIF; T/T, 30% in advance and 70% balance before shipping.
3. How about the delivery time?
Answer: Commonly, it takes 15~35 days of production after the receipt of your advance down payment and 7 days for delivering after full payment.
4. What is the warranty time?
Answer: 12 month from the date of supply for vehicles; technical support and spare parts supply liftlong.
5. What is the packaging?
Answer: bulk ship, ro-ro ship, container ship, flat rack, etc.
Professional, economic and safe methods and measures to package trucks or equipments.
6. Can we supply samples if customers need sample in advance?
Answer: If we just right have the sample in stock, we can supply it for you. But the customer need pay for the cost.
7. How to establish a long term cooperation?
Answer: We try our best to guarantee great quality and good price policy for our old customers to ensure the benefits of our customers. Moreover, we respect every customer and sincerely do business, making friends with them, no matter who they are, wherer they are from.
A: We are a leading manufacture of pressure vessels,bobtails,trailers, trucks, and skid mounted stations,and spare parts. Welcome to visit us in Suizhou city, the production base of Chinese special purpose vehicles.
2. Q: Where is your factory located?
A: We are located in Suizhou City,Hubei Province,China
3.Q:How can i visit there?
A:Welcome to the factory for inspection. You can fly to Wuhan Tianhe Airport, and our company will arrange a special car to pick you up.
4.Could you customize exactly according to my requirements?
A:Yes. We have professional R&D team, we can produce the product exactly according to your requirements.
5.Q: Do you provide certification that we need?
A:We can provide various certifications associate. Such as BV,DOT, ADR, SASO and so on.
6.Q: what's your payment terms?
A:T/T& L/C are preferred.
7.Q:Do you arrange shipment for the vehicles?
A:Yes,we can arrange shippment based on trade terms.
8. Q:What service can I get from you?
A:We provide lifelong tracking service and one year free warranty for all of our products. Meanwhile we provide free training and technical support to guide you repair your product. If need, we will also send original spare parts free of charge by air.
9.Q:How is the packing?
A:All the packing comply with exporting standard.
10.Q:How long is the lead time?
A:20-25 working days.
For other questiones,we will reply you ASAP after receiving your consult!
