Garbage compactor truck is the most popular type for waste management companies. It is mainly suitable for the collection and transportation of garbage in various places such as municipal sanitation, property management, large-scale factories, industries, and mines. CLW Group has more than 18 years experience on design and produce garbage trucks which including garbage compactor truck, Hook Lift Garbage Truck, swing arm Garbage Truck.
Main feature
1. Truck chassis: ISUZU,Dongfeng, HOWO,Foton, Shacman, JAC, JMC, FAW, CAMC etc.
2.Types of models: single axle, front four rear four, front four rear six, rear eight wheels, front four rear eight, second axle semi-trailer, three-axle semi-trailer, etc.
3. Garbage bin box size various from 5cbm, 6cbm,8cbm,10cbm, 12cbm, 14cbm, 16cbm, 18cbm, 20cbm, 22cbm, 25cbm, 30cbm, 35cbm,45cbm .
4. Garbage bin box material: high intense carton steel, from Well-known steel mills in China.
5. PLC control system from driver cabin and rear side of truck, easy operate by the workers.
6. multi type rear loading type for choice, customized design based on user's need.
7. High efficient compression rate 0.6 to 0.8 depends on the waste type.
8.The garbage can be completely compressed by the full hydraulic control operating system.
9.The utility model can realize the combined operation of a car and a plurality of garbage compartments, circulate transportation, and fully improve the transportation capacity of the vehicle
Our garbage Compactor truck has the features :
a. reasonable structure,simple and stable operation; High efficiency; Good sealing performance; Easy Dumping;
b. With dump function and hydraulic operation, very easy to collect the garbage;
c. The lifting mechanism use the lifting base support device, which can decrease the error generated during the preparation, make the mechanism move smoothly, and extend the service life of the lifting mechanism.
d. The sliding block of the ejector is made of high wear resistance alloy material with long service life.
Chassis 机壳 Chassis Brand 底盘品牌 FOTON Drive Type 驱动类型 4×2 left/right hand drive Wheelbase(mm) 轴距 4600 Tire Specifications 轮胎规格 11.00R20 The Number of Tires 轮胎数量 6pcs with one spare tire Dimensions(mm) 尺寸 7500×2500×3250 Air Conditioner A/C Brake System 制动系统 Air break Steering Gear 转向装置 Power steering, hydraulic steering with power assistance Gear box 齿轮箱 9 Forwards & 1Reverse , manual operated Max. driving speed(km/h) 最大速度 95 Engine 引擎 Model型号 Weichai Horsepower(HP) 马力 270HP Emission standard 排放标准 Euro 2/3/4/5 Optional Cylinder No. 气缸数 6 cylinders in-line, four strokes, water-cooled, turbo-charged intercooling, direct injection Fuel type 燃料类型 Diesel Cabin 舱 1 Sleeper , 3 Passengers,single row
Technical Parameters Effective volume of trash bin 10-15m³ Filler volume 1.5m³ Rated pressure of hydraulic system 19（Mpa） Loader working time ≤25（mm） Trash dumping time ≤40（s） Filler lifting time ≤12（s） Wastewater tank volume ≥300（L） Manipulator flip quality ≥600（Kg） Back flip form Hanging bucket Top material Front box 5mm bottom plate, 4mm side plate, 3mm top plate, Q345 steel plate Dozer Q345B steel plate Stuffer Q345B steel plate Scraper skateboard assembly Q345B steel plate Rear flip device Q345B steel plate and profile Subframe material Made of Q345 manganese plate Hydraulic system Cylinder Foshan naval power Oil pump Hefei Changyuan Multi-way valve Hefei Changyuan Process requirements Corrosion inside the tank Industrial grade anti-corrosion Welding and spraying requirements Execute in accordance with "Fukuda Overseas Compression Garbage Truck Top Installation Specification" Glue requirements The tank body, mudguard, sub-frame welded joints and side lights need to be treated with sealant
(Curved box)
FAQ
1.what can you buy from us?
Answer: Fire Truck ,LPG Tank Truck,Fuel Tank Truck, Tank Truck ,Cleaning Truck,Garbage Truck, Tow Truck , Bucket Truck ,Construction Truck, Ambulance , Van Truck ,Truck Mounted Crane,Utility Truck,Tank Semi Trailer, Semi Trailer
2. What is the payment term?
Answer: FOB,CIF; T/T, 30% in advance and 70% balance before shipping.
3. How about the delivery time?
Answer: Commonly, it takes 15~35 days of production after the receipt of your advance down payment and 7 days for delivering after full payment.
4. What is the warranty time?
Answer: 12 month from the date of supply for vehicles; technical support and spare parts supply liftlong.
5. What is the packaging?
Answer: bulk ship, ro-ro ship, container ship, flat rack, etc.
Professional, economic and safe methods and measures to package trucks or equipments.
6. Can we supply samples if customers need sample in advance?
Answer: If we just right have the sample in stock, we can supply it for you. But the customer need pay for the cost.
7. How to establish a long term cooperation?
Answer: We try our best to guarantee great quality and good price policy for our old customers to ensure the benefits of our customers. Moreover, we respect every customer and sincerely do business, making friends with them, no matter who they are, wherer they are from.
A: We are a leading manufacture of pressure vessels,bobtails,trailers, trucks, and skid mounted stations,and spare parts. Welcome to visit us in Suizhou city, the production base of Chinese special purpose vehicles.
2. Q: Where is your factory located?
A: We are located in Suizhou City,Hubei Province,China
3.Q:How can i visit there?
A:Welcome to the factory for inspection. You can fly to Wuhan Tianhe Airport, and our company will arrange a special car to pick you up.
4.Could you customize exactly according to my requirements?
A:Yes. We have professional R&D team, we can produce the product exactly according to your requirements.
5.Q: Do you provide certification that we need?
A:We can provide various certifications associate. Such as BV,DOT, ADR, SASO and so on.
6.Q: what's your payment terms?
A:T/T& L/C are preferred.
7.Q:Do you arrange shipment for the vehicles?
A:Yes,we can arrange shippment based on trade terms.
8. Q:What service can I get from you?
A:We provide lifelong tracking service and one year free warranty for all of our products. Meanwhile we provide free training and technical support to guide you repair your product. If need, we will also send original spare parts free of charge by air.
9.Q:How is the packing?
A:All the packing comply with exporting standard.
10.Q:How long is the lead time?
A:20-25 working days.
For other questiones,we will reply you ASAP after receiving your consult!
